The S5 is a sport-wide benchmark for speed and aerodynamic efficiency—with the race results to back it up. From Wout van Aert winning the Green Jersey by the biggest margin of victory in modern history, to Simon Yates riding himself into the maglia rosa, S5’s iconic V-stem and bayonet fork are a fixture at the front of the professional peloton. The new S5 builds on that legacy of speed by getting even faster.

The new bike is over 6 Watts faster than its predecessor, 124 grams lighter, and retains the handling, poise, and stability that riders everywhere love. The biggest changes are at the front of the bike, where the most significant aerodynamic performance comes from. The fork legs and head tube got quite a bit deeper, and the all-new, one-piece handlebar/stem builds on the original V-stem concept—and gets even faster.

Cervélo and Reserve co-developed the new Reserve 57|64 Turbulent Aero wheels specifically for use in the S5 frame, completing the aerodynamic system.

Aero Aero Aero

The new S5 is 6.3 Watts faster than its predecessor. These gains are realized primarily at the front end of the bike, but the integration of the asymmetric profiles of the seat tube and rear wheel are a significant source as well. Cervélo has long been the aerodynamic leader in the peloton, and we’re confident that the new S5 is at least 5 Watts faster than the bikes of our competitors.

One-Piece Handlebar/Stem

HB19 uses our “Plus-Four” concept, meaning the dimension at the hoods is 4cm narrower than in the drops (e.g. 38cm/42cm). This approach helps riders maintain a more aero body position while their hands are on the hoods, and provides stability in the drops for descending and sprinting. All bar sizes are UCI-legal, even in light of the most recent regulations change.

Not just faster. Lighter, too.

Despite an increase in surface area, the new S5 is 124 grams lighter than its predecessor. While the increase in fork and head tube depth added weight, we optimized the layup and hardware to make the system lighter.

Reserve 57|64 Designed for S5:

The new Reserve 57|64 wheelset was co-developed by Reserve and Cervélo, and designed for use in the new S5. The rear wheel’s asymmetry matches the seat tube, ensuring air flows smoothly over both. The new wheelset is 3 Watts faster than the 52|63 wheels, and weighs the same.

Specs

FORK: Cervélo All-Carbon, Bayonet S5 Fork
HEADSET: FSA SL IS2 1-1/8, 36° x 45° / 1-3/8,
36° x 45°
FRONT THRU AXLE: Cervélo Aero Thru Axle Front, M12x1.5mm, 122mm length
REAR THRU AXLE: Cervélo Aero Thru Axle Rear, M12x1.0mm, 169mm length
FRONT WHEEL: Reserve 57TA, DT Swiss 180 DICUT,
12x100mm, 24H, centerlock, tubeless compatible
REAR WHEEL: Reserve 64TA, DT Swiss 180 DICUT,
12x142mm, XDR freehub, 24H, centerlock, tubeless compatible
TIRES: Vittoria Corsa Pro TLR G2.0 700x29c
CRANKSET: SRAM Red 1 AXS E1, 50T Aero,
DUB, with power meter
BOTTOM BRACKET: SRAM DUB Ceramic, BBright

CHAIN: SRAM Red E1
REAR DERAILLEUR: SRAM Red XPLR AXS E1
CASSETTE: SRAM Red XPLR E1, 10-46T,
13-Speed
SHIFTER/BRAKE: SRAM Red AXS E1
COCKPIT: Cervélo HB19 Carbon
SADDLE: Selle Italia NOVUS BOOST EVO
SuperFlow Carbon
SEATPOST: Cervélo SP34 Carbon
BRAKE ROTORS: SRAM Paceline X Centerlock
SIZES: 48, 51, 54, 56, 58
