BMC Kaius 01 ONE
BMC Kaius 01 ONE
Couldn't load pickup availability
The ultimate gravel racer: speed, stability, performance. With advanced carbon frame, SRAM Red XPLR, ICS Carbon Aero one-piece cockpit and CG 39 SL wheels.
We’ve turned gravel racing into an obsession, and the Kaius 01 ONE is the result. Born from a dream of ultimate speed, it’s a machine designed to crush every race. Engineered by BMC's Impec Lab with cutting-edge composite carbon technology, the Kaius 01 ONE is the pinnacle of gravel performance. With race-optimized geometry, it offers the perfect balance of stiffness, lightness, and compliance, boosting traction on loose terrain, front-end stability, and climbing power. Featuring ICS cable integration and Aerocore design, this carbon gravel bike is built to fly. Outfitted with a full SRAM Red XPLR groupset, power meter, and CG 39 SL Carbon wheelset, it’s ready to dominate your next season.
Frameset
Frame:
Kaius 01 Premium Carbon with Aerocore Design | ICS Technology Stealth Cable Routing | UDH Dropout (Universal Derailleur Hanger) | TCC Race Compliance Level | Flat Mount Disc | 12 x 142mm Thru-Axle
Fork:
Kaius 01 Premium Carbon | ICS Technology, Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Handlebar:
ICS Carbon Aero | One-Piece Full Carbon Cockpit | 135mm drop, 77mm reach, 12.5° flare
Seat
Seatpost:
Kaius 01 Premium Carbon D-Shaped Seatpost | 15mm Offset | D-Fender Compatible
Saddle:
Fizik Vento Argo X1 Carbon | 140mm
Drivetrain
Crankset:
SRAM Red XPLR AXS DUB Wide E1
Chainrings:
42T
Power Meter:
SRAM Red AXS Power Meter (FC-RED-P-E1)
Cassette:
SRAM Red XPLR (CS-XG-1391-E1)
Cassette Size:
10-46T
Chain:
SRAM RED (CN-RED-E1)
Rear Derailleur:
SRAM Red XPLR AXS (RD-RED-1E-E1)
Shifters:
SRAM Red AXS (ED-RED-E1)
Gears:
1 x 13
Bottom Bracket:
SRAM Press Fit DUB
Brakes
Brake Levers / Calipers:
SRAM Red AXS (ED-RED-E1)
Rotors:
SRAM Paceline X | Centerlock
Rotor Size (F/R):
160 / 160mm
Wheels
Rims:
CG 39 SL Carbon | Tubeless Ready | 39mm
Hubs (F/R):
CG 39 SL for Carbon Spokes | Star Ratchet Freehub | Center Lock
Tires:
Pirelli Cinturato Gravel H | 40mm
Tubeless Information:
Tubeless Rim | Tubeless Tires
Accessories
In the Box:
Aerocore Bottle Cages | Computer mount for Garmin and Wahoo
Additional Information
Tire Clearance:
44mm measured tire
Weight without Pedals:
7.5kg | Size 54 as pictured with all accessories
ASTM Classification:
Level 2
System Weight Limit:
120kg
**We offer free assembly and tuning for bikes purchased for in-store pickup. Shipped bikes will be delivered partially assembled in the box and require some assembly and tuning.
